Dμrt Hog Wall Panel

Dμrt Hog Wall Panel

The Dμrt Hog wall panel filtration system is a stationary unit that will continuously filter the fluid in your tank to maintain a consistent level of cleanliness. We can customize this to fit whatever system requirements you have. Just let us know your problem and we will help you find a find a solution.

  • Flow Rate: 3-30 Gpm (11.5-113 LPM)
  • Voltage: 115/230 1 Ph Or 230/460 Vac 3Ph
  • Viscosity: Up To 1050 CST (5000 Sus)
  • Max Pressure:L 100 Psi (7 Bar)
  • Operating Temperature: 40°F To 200°F (-40°C To 93°C)
  • Bypass Valve Setting: 65 Psi
  • Compatibility: Any Fluid Compatible With Viton
  • Weight: Varies By Size
  • Dimensions: Varies By Size
Features:
  • Panel Mount Kidney Loop
  • Multiple Rate Flow Options
  • Multiple Voltage Options
  • Pall High Efficiency Filter
  • One Eye Magnetic Scrubber
  • Heavy Duty Gear Pump

Download Data Sheet

Dµrt Hog CAD | Applied Energy Co
